HC-S600 Conveyor Belt AI Visual UV Printer

AI Visual UV Printer

Technical Specifications & Advanced Features

Core Technical Parameters

• Printhead: Ricoh G6/GH2220 / Toshiba CE4M | 2-4 pcs (automatic configuration)
• Print Resolution: 600-1800DPI
• Color Configuration: W+CMYK+LcLm+V | Customizable special spot colors/multi-ink combinations
• Ink System: 2.5L ink tank per color | US/Japan/Korea imported & self-developed eco-friendly UV ink
• RIP Software: German COLOR GATE | Compatible with Photoshop/CoreIDRAW/Illustrator
• File Format: PDF, JPEG, EPS, TIFF, etc.
• Print Range: Max print width 600mm | Media thickness 2-200mm
• Transmission & Curing: High-precision conveyor belt transmission | LED UV instant curing
• Power & Weight: Operating power 10KW | 200-240VAC single-phase 50/60Hz | Machine weight 1100KG
• Working Env: Temperature 20-28℃ | Humidity 40%-70% (non-condensing)
• Interface & Dimensions: Ethernet data interface | Packaging dimensions 1800×1800×1450mm/1900×1900×1650mm
• Color Management: ICC-based color adjustment, density adjustment, true-to-original color reproduction

Advanced Core Features

1. Dual AI Visual Positioning: Linear/camera vision optional, automatic capture/scanning/contour recognition, high-precision pattern matching for special-shaped products
2. Mold/Fixture-Free Printing: No manual positioning or molds required, intelligent batch recognition and matching, saving labor and mold costs while improving efficiency
3. Continuous Conveyor Belt Transmission: High-precision belt transport realizes uninterrupted batch printing, suitable for industrial mass production of small and medium format products
4. Multi-Image Intelligent Matching: Same printing height supports mixed printing of different products, no layout required, making small-batch multi-variety printing more efficient
5. High-Quality Ink & Color Management: Imported eco-friendly UV ink with strong adhesion, fade/scratch/water resistance; German COLOR GATE RIP ensures excellent color processing and consistent reproduction
6. Flexible Configuration & Easy Operation: 2-4 printheads configurable, support custom spot colors; simple operation interface, compatible with mainstream design software, low professional threshold
7. Stable Industrial Performance: Integrated industrial structure design, 1100KG solid weight, stable operation without offset during high-speed continuous printing, low failure rate

Unmatched Advantages Over Conventional Printers

1. Intelligent Visual Positioning, Zero Manual Error: AI automatic recognition and positioning solve the low accuracy problem of traditional manual positioning, perfectly adapting to the printing of special-shaped products
2. Mold-Free Production, Cost & Labor Saving: Abandon traditional molds and fixtures, eliminate mold making and replacement costs, adapt to small-batch, multi-variety production needs, and reduce labor input
3. Continuous Conveyor Belt, High Production Efficiency: Conveyor belt uninterrupted transmission realizes automatic batch printing, greatly improving production capacity compared with traditional flatbed printers
4. Wide Material Adaptability, Strong Compatibility: Supports 2-200mm thick media, suitable for various rigid materials, meeting the diverse printing needs of different industries
5. High Precision & Stable Quality: 600-1800DPI high resolution, fine ink dots and precise placement; ICC color adjustment ensures consistent color for mass production, no color deviation
6. Eco-Friendly & Durable Output: SGS compliant eco-friendly UV ink, no harmful emissions, strong ink adhesion, fade-resistant for outdoor long-term use, meeting industrial environmental standards
7. Compact Design, Easy Deployment: Reasonable structural layout, small floor space, suitable for small and medium workshops and production lines, easy to integrate with existing production processes

Diverse Industrial Applications

• Packaging Industry: Irregular packaging boxes, gift boxes, paper cards, tags, small packaging containers, cosmetic mini packaging
• Advertising & Signage: Small acrylic signs, PVC/KT boards, special-shaped advertising ornaments, customized nameplates, metal signs
• Hardware & Electronics: Small hardware parts, electronic product casings, precision plastic accessories, electronic labels, small circuit board accessories
• Gifts & Crafts: Customized gift boxes, special-shaped crafts, metal/plastic gifts, decorative pendants, personalized badges
• Stationery & Daily Necessities: Customized stationery, small plastic daily necessities, glass crafts, ceramic small ornaments, shoe accessories
• Toys & Sporting Goods: Small toy parts, personalized sporting goods accessories, plastic toy casings, craft ornaments
